Product Details
Place of Origin: China
Brand Name: Shineplus
Certification: ISO13485,ISO9001,UL,ROHS2.0
Model Number: UL2464 or customized
Payment & Shipping Terms
Minimum Order Quantity: 50 pcs
Price: Negotiation
Packaging Details: Cartons
Delivery Time: Negotiable
Payment Terms: Negotiable
Supply Ability: 8000 pcs/day
Product Name: |
UL1007 24AWG 4PIN Plastic Case, 100mm White Pvc Transparent Sheath Insulated Display Panel Electronic Wiring Harness |
Application Area: |
Electronic Equipment |
Wire Type: |
UL1007 24AWG |
Conductor Material: |
Copper Or Oxygen-free Copper |
Conector: |
4PIN Plastic Case, Pvc Transparent Sheath |
Color: |
White |
Length: |
100mm |
Rated Voltage: |
300V |
Insulation Impedance: |
≥10Ω |
Work Temperature: |
-40~+105℃ |
MOQ: |
50 Pcs |
Packing: |
Cartons |
OEM,ODM: |
Accept |
Code: |
FDL464A1553 |
Product Name: |
UL1007 24AWG 4PIN Plastic Case, 100mm White Pvc Transparent Sheath Insulated Display Panel Electronic Wiring Harness |
Application Area: |
Electronic Equipment |
Wire Type: |
UL1007 24AWG |
Conductor Material: |
Copper Or Oxygen-free Copper |
Conector: |
4PIN Plastic Case, Pvc Transparent Sheath |
Color: |
White |
Length: |
100mm |
Rated Voltage: |
300V |
Insulation Impedance: |
≥10Ω |
Work Temperature: |
-40~+105℃ |
MOQ: |
50 Pcs |
Packing: |
Cartons |
OEM,ODM: |
Accept |
Code: |
FDL464A1553 |
UL1007 24AWG 4PIN plastic case, 100mm white pvc transparent sheath insulated display panel electronic wiring harness
1. Product description
UL1007 24AWG 4PIN plastic case, 100mm white pvc transparent sheath insulated display panel electronic wiring harness UL1007 standard with
24AWG wire. Suitable for low current applications. The electronic harness is equipped with a 4-pin plastic case connector for insertion into the
corresponding interface of the display or other electronic devices. Plastic case connectors provide easy plugging and unplugging, making the
electronic harness easy to install and replace. The electronic harness is wrapped with an insulating tape on the outside of the harness for
additional protection. The insulation tape can increase the insulation performance of the wiring harness, improve the durability and anti-
interference ability of the wiring harness. The cable harness of the TV display screen is made of transparent sheath made of white PVC material,
with beautiful appearance. The transparent sheath makes the wires and connectors inside the harness clearly visible for easy installation and
maintenance.
Feel free to contact with us, if you ever needed to consider your wire harness solution.
|
Product Name |
UL1007 24AWG 4PIN plastic case, 100mm white pvc transparent sheath insulated display panel electronic wiring harness |
|
Harness material |
Pass ISO13485,ISO9001,UL and ROHS2.0 certification |
|
Product application |
Electronic equipment |
|
Length, color |
Customized according to customer needs |
|
Samples |
Samples confirmed first before mass production |
|
Serve |
Whole-course specially-assigned follow-up, to provide fast and efficient service |
|
Test requirement |
Bending resistance: ≥5 million times,Salt spray test: ≥72H,Tensile test 1000N |
|
MOQ |
Negotiable |
|
After-sales service |
Authentic guaranteed, factory outlets center |
3. Picture of real products
4. Application area
I: Computer monitor: The display electronic wiring harness is suitable for connecting computer monitor and related equipment, transmitting video signals, power signals and other control signals.
II: Industrial displays: This display electronic wiring harness is widely used in the industrial sector to connect industrial displays, touch screens, controllers, and other devices.
III: Automotive navigation systems: The display electronic wiring harness can be used to connect the display, audio devices, and control units in automotive navigation and entertainment systems.
5. Feature
I: High temperature resistance: UL1007 electronic display harness has good high temperature resistance. The UL1007 standard requires wiring harnesses to operate within a certain temperature range, typically between 80°C and 105°C.
II: Electrical insulation performance: The insulation performance of the electronic display harness conforms to UL1007 standard, which can effectively isolate the wires and prevent current leakage and electrical short circuit.
III: Easy installation and maintenance: The plastic case connectors and transparent sheath design of the electronic display harness make it easy to install and maintain, reducing working time and labor costs.
